TDE MACNO MINIOPD EXP User Manual page 118

Name
DEAD_TIME_HW
MIN_PULSE
EN_AI1
EN_AI2
EN_AI3
AI1_SEL
AI2_SEL
AI3_SEL
TF_TRQ_REF_AN
EN_AI16
AI16_SEL
PRC_SPD_JOG
EN_SPD_JOG
PRC_START_DG_POT
EN_MEM_DG_POT
PRC_MAX_REF_DG_POT
PRC_MIN_REF_DG_POT
DG_POT_RAMPS
EN_DG_POT
TIME_DEC_FRQ_SEL
FRQ_IN_PPR_SEL
FRQ_IN_NUM
FRQ_IN_DEN
EN_FRQ_REF
FRQ_REF_SEL
TF_TIME_DEC_FRQ
KP_TIME_DEC_FRQ
SB_MOT_SPD_MAX
SB_SPD_REG_KP
SB_SPD_REG_TI
SB_SPD_REG_TF
SB_CW_ACC_TIME
SB_CW_DEC_TIME
SB_CCW_ACC_TIME
SB_CCW_DEC_TIME
SB_ON
EN_LIN_RAMP
EN_INV_SPD_REF
EN_I_CNTRL
EN_POS_REG
EN_POS_REG_MEM_CLR
MUL_AI_IN_SEL
MUL_AI_OUT_SEL
MUL_AI_MAX
MUL_AI_MIN
MUL_KCF_MAX
MUL_KCF_MIN
118
Description
P198 - Dead time hardware duration
P199 - Minumum command pulse duration
P200 - Enable analog reference value A.I.1
P201 - Enable analog reference value A.I.2
P202 - Enable analog reference value A.I.3
P203 - Meaning of analog input A.I.1
P204 - Meaning of analog input A.I.2
P205 - Meaning of analog input A.I.3
P206 - Filter time constant for analog torque
reference value
P207 - Enable analog reference value A.I.16
P208 - Meaning of analog input A.I.16
P211 - Digital speed reference value (JOG1) -100.00
P212 - Enable jog speed reference
P213 - Motor potentiometer starting speed
P214 - Load final digital potentiometer
reference value
P215 - CW motor potentiometer speed
reference value
P216 - CCW motor potentiometer speed
reference value
P217 - Digital potentiometer acceleration
time
P218 - Enable motor potentiometer
reference value(A.I.4)
P219 - Meaning of frequency speed
reference value decoded in time
P220 - Encoder pulses per revolution
P221 - NUM - Frequency input slip ratio
P222 - DEN - Frequency input slip ratio
P223 - Enable frequency speed reference
value
P224 - Frequency speed reference selection
P225 - Filter time constant of frequency
input decoded in time
P226 - Corrective factor for frequency input
decoded in time
P227 - Second bank Max. operating speed
P228 - Second bank KpV speed regulator
proportional gain
P229 - Second bank TiV speed regulator
lead time constant
P230 - Second bank TfV speed regulator
(filter) time constant
P231 - Second bank CW acceleration time
P232 - Second bank CW deceleration time
P233 - Second bank CCW acceleration time
P234 - Second bank CCW deceleration time
P235 - Second bank active
P236 - Enable linear ramp
P237 - Invert reference signal software
P238 - Enable only current control
P239 - Enable overlapped space loop
P240 - Enable overlapped space loop
memory clear in stop
P241 - Multiplication factor selection
P242 - Multiplication factor target
P243 - Max analog input value for
multiplication factor
P244 - Min analog input value for
multiplication factor
P245 - Multiplication factor with max analog
input (MUL_AI_MAX)
P246 - Multiplication factor with min analog
input (MUL_AI_MAX)
Min Max Default
0.0 20.0 0.0
0.0 20.0 1.0
0 1 0
0 1 0
0 1 0
0 4 0
0 4 1
0 4 2
0.0 20.0 0
0 1 0
0 4 0
100.0
0 % MOT_SPD_MAX
0
0 1 0
-100.0 100.0 2.00 % MOT_SPD_MAX
0 1 0
-105.0 105.0 105.02 % MOT_SPD_MAX
-105.0 105.0 -105.02 % MOT_SPD_MAX
1999.
0.3 50
9
0 1 0
0 3 0
0 9 5
-16383 16383 100
0 16383 100
0 1 0
0 2 0
0.0 20.0 1.6
0.0 200.0 100
50 30000 3000
0.1 400.0 6
3000.
0.1 30
0
0.0 25.0 0.4
199.9
0.01 10
9
199.9
0.01 10
9
199.9
0.01 10
9
199.9
0.01 10
9
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 4 0
0 2 0
180.0
-180.00 100.0
0
180.0
-180.00 0.0
0
-100.0 100.0 1.0
-100.0 100.0 -1.0
UM Scale
µs 10
µs 10
1
1
1
1
1
1
ms 10
1
1
163.84
1
163.84
1
163.84
163.84
s 10
1
1
1
1
1
1
1
ms 10
163.84
rpm 1
10
ms 10
ms 10
s 100
s 100
s 100
s 100
1
1
1
1
1
1
1
1
% A.I. 163.84
% A.I. 163.84
100
100
