2.1.1.1 DRIVE CURRENT OVERLOAD SELECTION
Four types of drive overload can be set on C56
C56
0
1
2
3
NB: the choice also changes the rated drive current as shown by the tables in the installation file and
the correct value is always displayed in ampere rms in P53.
The delivered current is also used to calculate the operating temperature reached by the power
component junctions with the drive presumed to be working with standard ventilation at the maximum
ambient temperature permitted.
If this temperature reaches the maximum value permitted for the junctions, the delivered power limit
is restricted to a value that is just over the rated drive current, i.e. the system's effective thermal
current (see following table).
Now the drive will only overload if the temperature drops below the rated value, which will only occur
after a period of operation at currents below the rated current.
The junction temperature calculation also considers the temperature increase that occurs while
operating at low frequencies (below 2.5 Hz) due to the fact that the current is sinusoidal and thus has
peak values that are higher than the average value. With electrical operating frequencies lower than
2.5Hz, the drive goes into maximum overload for 20-30ms after which the maximum current limit is
reduced by √2 as shown by the following table:
C56 Max. drive current
0 120% I NOM AZ for 30 seconds
1 150% I NOM AZ for 30 seconds
2 200% I NOM AZ for 30 seconds
200% I NOM AZ for 3 seconds
3‫٭‬
155% I NOM AZ for 30 seconds
N.B. = the overload time illustrated is calculated with the drive running steady at the rated motor
current. If the average delivered current is lower than the rated motor current, then the overload time
will increase. Thus the overload will be available for a longer or identical time to the ones shown.
N.B. 3‫ = ٭‬the 200% overload is available until junction temperatures are estimated to be 95% of the
rated value; at the rated value the maximum limit becomes 180%. For repeated work cycles, TDE
MACNO is available to estimate the drive's actual overload capacity

2.1.2 MOTOR PLATE

Name Description
P61 - Rated motor
PRC_MOT_I_NOM
current ( I NOM MOT)
P62 - Rated motor
MOT_V_NOM
voltage
P63 - Rated motor
MOT_F_NOM
frequency
P64 - Max. operating
PRC_MOT_V_MAX
voltage
8
Overload type for rated drive current (P53)
120% for 30 seconds
150% for 30 seconds
200% for 30 seconds
200% for 3 seconds and 155% for 30 seconds
Drive thermal current
103% I NOM AZ
108% I NOM AZ
120% I NOM AZ
110% I NOM AZ
Min Max Default
10.0 100.0 100
100.0 1000.0 380
10.0 800.0 50.0
1.0 200.0 100
Limit below 2.5 Hz
84% I NOM AZ
105% I NOM AZ
140% I NOM AZ
140% I NOM AZ
UM Scale
% DRV_I_NOM 327.67
Volt 10
Hz 10
% MOT_V_NOM 40.96
