TDE MACNO MINIOPD EXP User Manual page 68

The simulated encoder outputs are all driven by a "LINE DRIVER". Their level in the standard drive
version is referred to +5V and then it is connected to the internal supply (TTL +5V).
In option (to be requested in the ordering) there is the possibility to refer the signal level to an
external supply whose value must be between +5V and +24V, connection on terminal 5 and 6.
In the connected device it is better to use a differential input to avoid loops with the 0V wire, to limit
noise effects it is better to load this input (10mA max).
It is necessary to use a twisted shielded cable to make a proper connection.
WARNING: the external power supply GND is connected with the 0V of the drive (it is not
WARNING: for the encoder simulation with internal supply (standard drive version) you must
not connect the terminal 5 (Vccin), because it could seriously damage the drive, and set the
WARNING: for the encoder simulation with external supply, you must connect the terminal 5
(Vccin) and 6 (GND) and set the SW1 switch as indicated in the follow image.
3.2.3.2 CONFIGURATION OF THE ENCODER SIMULATION OUTPUT
The two bidirectional simulation encoder channels could have a number of pulses per motor
revolution selectable with C51 according to the following table, that also depends on the number of
sensor polar couples:
68
optoisolated).
SW1 switch as indicated in the follow image.
SW1
ON
SW1
ON
C51 Pul/rev motor/(P68/2)
0
1
2
3
4
5
6
7
8
9
10
11
1
1
0
64
128
256
512
1024
2048
4096
8192
16384
32768
65536
