7 DISPLAY

7.1 PHYSICAL DISPOSITION
The keypad has three buttoms, "S" ( selection), "+" (increase), "-" (reduce) and a four numbers and
half display, with the decimal points and the sign "-".
OPD EXP
7.2 LAYOUT OF THE INTERNAL DIMENSIONS
The converter is a full digital, then other hardware settings are not
necessary, if not made in factory, and the setups, settings and
visualizations, all digital, they go effect through the keypad and the display,
or by serial line or by fieldbus. For easy access of formulations and
mnemonics all the accessible greatnesses have been grouped in the
following menu:
• Parameters (PAR)
• Application Parameters (APP)
• Connections (CON)
• Internal dimensions (INT)
• Allarms (ALL)
• Digital Input (INP)
• Digital Output (OUT)
User's manual
MINIOPD EXP
FIG. 1 (Physical disposition)
