TDE MACNO MINIOPD EXP User Manual page 79

4.1.2.3 15 (OF HEX) FORCE MULTIPLE COILS
This function enables to set the value of digital inputs via serial line. As previously said, the digital
inputs via serial line are all parallel to the related digital inputs via terminal board except the RUN
enable ( where the two inputs are in series )
Starting address
Starting address(hex)
4.1.2.4 16 (10 HEX) PRESET MULTIPLE REGISTERS
This function allows to set the value of the parameters, connections and to enable the alarms even if
the corresponding keys are opened.
To correctly set these data it is required the right address ( that you can find in the following table)
and it is necessary to consider the internal data representation, referring to the specific descriptions
of the core. The application area's meaning depends on the present application (see specific
documentation):
starting address
0000
00C8
012C
0203
0360
If it is written a value not included in the range, the value will be ignored and the previous one will
remain valid.
4.1.2.5 EXCEPTION RESPONSES
The following exception codes in the answer are managed:
Code
01
02
03
User's manual
Max data number
Max data number
0360
Max data number
200
100
100
1
1
Name
Not managed function The drive doesn't manage this Modbus function
Wrong data address
Wrong data value
Digital inputs
Description
32 Digital inputs
Description
Parameters table
Connections table
Applications data table
Alarms enabling
Digital input
Description
The address is not valid
The data number required is too big
79
