TDE MACNO MINIOPD EXP User Manual page 117

Name
K_FLX97
BRAKE_R_MAX_POWER
K_FLX100
K_FLX102
KP_POS_VF
PRC_DEAD_TIME_CMP_XB P151 - Xb = cubic coupling zone amplitude
PRC_DEAD_TIME_CMP_YC
PRC_DEAD_TIME_CMP_X0 P153 - Xoo = dead zone amplitude
PW_SOFT_START_TIME
OVR_LOAD_T_ENV
DRV_F_PWM_CARATT
DEAD_TIME
PRC_I_DECOUP
KP_NEG_VF
I_DELAY_COMP
V_DELAY_COMP
ID_CANOPEN
KP_SINCOS1_CHN
OFFSET_SIN1
OFFSET_COS1
DRV_E_CARATT
SPD_REG_KD_TF2
START_TIME
PRC_VF_SLIP_CMP
VF_TF_SLIP_CMP
PRC_VF_BOOST
PRC_VF_DCJ_I_MAX
PRC_VF_DCJ_F_MAX
PRC_VF_CHR_V1
PRC_VF_CHR_F1
PRC_VF_CHR_V2
PRC_VF_CHR_F2
DB1_START
DB1_END
DB2_START
DB2_START
PRC_VF_V_REG_D
PRC_VF_FSTART_SEARCH
PRC_VF_FMIN_SEARCH
VF_STALL_TIME
PRC_VF_V_MAX_STATIC
VF_TI_ENGY
PRC_VF_FLX_MIN_ENGY
VF_TF_I_MAX_AL
PRC_VF_T_MAX_SEARCH P191 - Torque limit during fly restart
User's manual
Description
P145 - Magnetic characteristic point 8
P146 - Maximum Power dissipated on
Braking resistance
P147 - Magnetic characteristic point 9
P149 - Magnetic characteristic point 10
P150 - High precision analog speed
reference value:VCO setting for positive
voltage reference values
P152 - Yc = compensation at rated drive
current
P154 - Soft start enabling time
P155 - Ambient temperature reference value
during overload
P156 - PWM frequency for drive definition
P157 - Dead time duration
P158 - Corrective coefficient for decoupling
terms
P159 - High precision analog speed
reference value:VCO setting for negative
voltage reference values
P160 - PWM delay compensation on the
currents
P161 - PWM delay compensation on the
voltages
P162 - CAN BUS node ID
P164 - Resolver or Incremental Sin/Cos sine
and cosine signal amplitude compensation
P165 - Resolver or Incremental Sin/Cos sine
offset
P166 - Resolver or Incremental Sin/Cos
cosine offset
P167 - Characterization voltage
P168 - Second order feedforword filter
P169 - Start up time
P170 - Slip motor compensation
P171 - Slip compensation factor filter
P172 - Stator voltage drop compensation
P173 - Current limit during continuous
braking
P174 - Continuous breaking maximum
frequency limit
P175 - V/f characteristic point 1 voltage
P176 - V/f characteristic point 1 frequency
P177 - V/f characteristic point 2 voltage
P178 - V/f characteristic poitn 2 frequency
P179 - Dead zone 1 initial speed
P180 - Dead zone 1 final speed
P181 - Dead zone 2 initial speed
P182 - Dead zone 2 final speed
P183 - Voltage regulator derivative
coefficient multiplying term
P184 - Initial search frequency with rotating
motor
P185 - Minimum search frequency with
rotating motor
P186 - Working time during limit
P187 - Vs amplitude maximum static value
P188 - Energy saving regulator filter time
constant
P189 - Energy saving admissible minimum
flux
P190 - Current alarm filter
Min Max Default
0.0 120.0 98.1
0.0 600.0 1.5
0.0 120.0 100.0
0.0 120.0 102.0
-16383 16383 4096
0.0 50.0 0.0 % DRV_I_NOM
50.0 100.0 100
DEAD_TIME_COMP
0.0 50.0 0 % DRV_I_NOM
150 19999 500
0.0 150.0 40
1000 16000 5000
0.0 20.0 4
0.0 200.0 0
-16383 16383 4096
-800.0 800.0 40
-800.0 800.2 50.0
1 127 1
0.0 200.0 100
-16383 16383 0
-16383 16383 0
200.0 780.0 400
1000.
0.0 0.0
0
0 19999 10
0.0 400.0 0.0
PRC_MOT_F_MAX
0.0 150.0 35.0
0.0 400.0 70.0 % PRC_DELTA_VRS 40.96
0.0 100.0 100.0 % DRV_I_NOM
0.0 100.0 0.0
PRC_MOT_F_MAX
0.0 100.0 0.0
PRC_MOT_V_MAX
0.0 100.0 0.0
PRC_MOT_F_MAX
0.0 100.0 0.0
PRC_MOT_V_MAX
0.0 100.0 0.0
PRC_MOT_F_MAX
0 30000 0
0 30000 0
0 30000 0
0 30000 0
0.0 100.0 100.0
0.0 100.0 100.0
PRC_MOT_F_MAX
0.0 100.0 2.9
PRC_MOT_F_MAX
1 100 30
0.0 100.0 97.5
PRC_MOT_V_MAX
100 2000 400
0.0 100.0 20.0 % MOT_FLX_NOM
0.0 150.0 10.0
0.0 100.0 150.0 % DRV_T_NOM
UM Scale
% 40.96
KWatt 100
% 40.96
% 40.96
1
163.84
%
327.67
163.84
ms 1
°C 10
Hz 1
µs 10
% 40.96
1
% TPWM 40.96
% TPWM 40.96
1
% 163.84
1
1
V rms 10
ms 10
ms 1
%
40.96
ms 10
40.96
%
40.96
%
40.96
%
40.96
%
40.96
%
40.96
rpm 1
rpm 1
rpm 1
rpm 1
% 327.67
%
40.96
%
40.96
s 40.96
%
327.67
ms 1
40.96
ms 10
40.96
117
