3 STANDARD APPLICATION

3.1 INPUT

3.1.1 ANALOG REFERENCE

Name
KP_AI1
OFFSET_AI1
AI1
EN_AI1
REF_AI1
AI1_SEL
KP_AI2
OFFSET_AI2
AI2
EN_AI2
REF_AI2
AI2_SEL
KP_AI3
OFFSET_AI3
AI3
EN_AI3
REF_AI3
AI3_SEL
TF_TRQ_REF_AN
User's manual
Description
P01 - Corrective factor for
analog reference 1 (AUX1)
P02 - Corrective offset for
analog reference 1 (AUX1)
D42 - Analog Input AI1
P200 - Enable analog
reference value A.I.1
D64 - Reference from Analog
Input AI1
P203 - Meaning of analog
input A.I.1
P03 - Corrective factor for
analog reference 2 (AUX2)
P04 - Corrective offset for
analog reference 2 (AUX2)
D43 - Analog Input AI2
P201 - Enable analog
reference value A.I.2
D65 - Reference from Analog
Input AI2
P204 - Meaning of analog
input A.I.2
P05 - Corrective factor for
analog reference 3 (AUX3)
P06 - Corrective offset for
analog reference 3 (AUX3)
D44 - Analog Input AI3
P202 - Enable analog
reference value A.I.3
D66 - Reference from Analog
Input AI3
P205 - Meaning of analog
input A.I.3
P206 - Filter time constant for
analog torque reference value
Min Max Default
-400.0 400.0 100
-100.0 100.0 0
-100 100 0
0 1 0
-100 100 0
Range
0 Speed ref.
1 Torque ref.
Torque limit
2
ref. 0
3 Set point PID
4 Feedback PID
Manual set
5
point PID
-400.0 400.0 100
-100.0 100.0 0
-100 100 0
0 1 0
-100 100 0
Range
0 Speed ref.
1 Torque ref.
Torque limit
2
ref. 1
3 Set point PID
4 Feedback PID
Manual set
5
point PID
-400.0 400.0 100
-100.0 100.0 0
-100 100 0
0 1 0
-100 100 0
Range
0 Speed ref.
1 Torque ref.
Torque limit
2
ref. 2
3 Set point PID
4 Feedback PID
Manual set
5
point PID
0.0 20.0 0
UM Scale
% 10
% 163.84
% 163.84
1
% 163.84
1
% 10
% 163.84
% 163.84
1
% 163.84
1
% 10
% 163.84
% 163.84
1
% 163.84
1
ms 10
