2.4 V/F CONTROL

Name
EN_VF_CNTL
PRC_VF_SLIP_CMP
VF_TF_SLIP_CMP
PRC_VF_BOOST
VF_EN_DCJ
PRC_VF_DCJ_I_MAX
PRC_VF_DCJ_F_MAX
VF_EN_CHR_AUTOSET
PRC_VF_CHR_V1
PRC_VF_CHR_F1
PRC_VF_CHR_V2
PRC_VF_CHR_F2
PRC_VF_V_REG_D
VF_EN_SEARCH
PRC_VF_FSTART_SEARCH
PRC_VF_FMIN_SEARCH
PRC_VF_T_MAX_SEARCH
VF_EN_STALL_ALL
VF_STALL_TIME
PRC_VF_V_MAX_STATIC
VF_EN_ENGY
VF_TI_ENGY
PRC_VF_FLX_MIN_ENGY
VF_TF_I_MAX_AL
VF_EN_OPEN_LOOP
VF_EN_BYPASS

2.4.1 AUTOMATIC SETTING OF WORKING VOLTAGE/FREQUENCY

"V/f control" manages the an asynchronous motor without feedback.
This type of control has a good dynamic performance also in flux weakening area (4-5 times base
frequency) and it's able to start the motor also with high load (2 times the nominal motor torque), but
44
