Objects' Dictionary : Manufacturer Specific Profile Area - TDE MACNO MINIOPD EXP User Manual

Index (hex) Object
1602 RECORD
1603 RECORD
1800 RECORD
1801 RECORD
1802 RECORD
1803 RECORD
1A00 RECORD
1A01 RECORD
1A02 RECORD
1A03 RECORD
4.2.6 OBJECTS' DICTIONARY : MANUFACTURER SPECIFIC PROFILE
AREA
The words reported in bold type can be mapped in PDO.
Index
Object
(hex)
2000 VAR
2001 VAR
2002 VAR
2003 VAR
2004 VAR
2005 VAR
2006 VAR
2007 VAR
2008 VAR
2009 VAR
200A VAR
200B VAR
200C VAR
200D ARRAY
200E ARRAY
200F ARRAY
2010 VAR
2011 VAR
2012 ARRAY
User's manual
Name
rd
3 receive PDO mapping
th
4 receive PDO mapping
st
1 transmit PDO parameter
nd
2 receive PDO parameter
rd
3 receive PDO parameter
th
4 receive PDO parameter
st
1 transmit PDO mapping
nd
2 transmit PDO mapping
rd
3 transmit PDO mapping
th
4 transmit PDO mapping
Type Name
INTEGER16 Block size
DOMAIN Tab_formati
DOMAIN Tab_con_formati
DOMAIN Tab_exp_int
DOMAIN Tab_exp_osc
DOMAIN Tab_par_def
DOMAIN Tab_con_def
INTEGER16 hw_software
INTEGER16 hw_sensore
INTEGER16 K_zz
INTEGER16 Via_alla_conta
DOMAIN Tab_monitor_A
DOMAIN Tab_monitor_B
INTEGER16 Tab_par [200]
INTEGER16 Tab_con [100]
INTEGER16 Tab_int [64]
UNSIGNED
Tab_inp_dig
32
UNSIGNED
Tab_out_dig
32
INTEGER16 Tab_osc [64]
Type
PDO Mapping
PDO Mapping
PDO CommPar
PDO CommPar
PDO CommPar
PDO CommPar
PDO Mapping
PDO Mapping
PDO Mapping
PDO Mapping
Description
SDO Block size Block
Download
Formats of the 200
parameters
Formats of the 100
connections
Formats of the 64 internal
values
Formats of the 64 monitor's
sizes
Values of the default
parameters
Values of the default
connections
Sensor managed by the
firmware
Sensor managed by
electronic card
Monitor counter
Monitor trigger
Data saved in the channel A
of the monitor
Data saved in the channel B
of the monitor
Actual values of the
parameters
Actual values of the
connection
Actual values of the internal
words
Actual values of the logical
input's functions
Actual values of the logical
output's functions
Actual values of the
checked words
Access
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Access
Reading/writing
reading
Reading
reading
Reading
Reading
Reading
Reading
Reading
Reading
Reading
Reading
Reading
Reading/writing
Reading/writing
Reading
Reading
Reading
Reading
85
