2.2.5.2 WAIT FOR MOTOR DEMAGNETIZING
When the drive is switched off it is dangerous to switch on immediately, due to the unknown magnetic
flux position that could produce a motor over–current. The only chance it's to wait the time needed for
the magnetic flux to reduce itself with its time constant that depend on the motor type and can vary
from few milliseconds to hundreds of milliseconds.
For this reason has been introduced the parameter P28 that set the wait time after power switch off
after that, it's possible to switch on the power another time: also if the user gives the RUN command
during this wait time, the drive waits to complete it before enabling another time the power.
Parameter P28 is defined in time units of 100us so the default value 10000 correspond to 1 second.
2.3

PROTECTION

2.3.1 VOLTAGE LIMITS

Name
MAIN_SUPPLY
DCBUS_MIN_MAIN_LOST
DCBUS_REF_MAIN_LOST
DCBUS_REG_KP
KP_DCBUS
DCBUS_MIN
DCBUS_MAX
DCBUS_BRAKE_ON
DCBUS_BRAKE_OFF
DCBUS_REF
RECT_BRIDGE_SEL
PW_SOFT_START_TIME
MAIN_LOST_SEL
ALL_RST_ON_MAIN
EN_DCBUS_MAX_CTRL
EN_PW_SOFT_START
DC_BUS
User's manual
Description
P87 - Main Supply voltage
P97 - Minimum voltage level for
forced mains off
P98 - Voltage reference value in
Support 1
P86 - Kp3 Bus control
proportional gain
P105 - Corrective factor for Bus
voltage
P106 - Minimum voltage of DC
Bus
P107 - Maximum voltage of DC
Bus
P108 - Bus voltage threshold for
brake ON
P109 - Bus voltage threshold for
brake OFF
P123 - Smart brake voltage cut-
in level
C45 - Rectification bridge 0 =
diodes, 1 = semicontrolled
P154 - Soft start enabling time
C34 - Managing mains failure
C35 - Automatic alarm reset
when mains back on
C47 - Enable smart brake
C37 - Enable soft start
D24 - Bus voltage
Min Max Default
180.0 780.0 400
100.0 1200.0 425
220.0 1200.0 600
0.05 10.00 3.5
80.0 200.0 100
220.0 1200.0 400
350.0 1200.0 800
350.0 1200.0 770
350.0 1200.0 760
300.0 1200.0 750
Range
0 Diods
0
Half controller
1
bridge
150 19999 500
Range
Trying to
0
work
1 Recovery 0
2 Free
Emergency
3
brake
0 1 0
0 1 0
0 1 1
0
UM Scale
V rms 10
V 10
V 10
100
% 10
V 10
V 10
V 10
V 10
V 10
1
ms 1
1
1
1
1
V 16
