The features in the 7 series FPGA DSP48E1 slice are:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
7 Series DSP48E1 User Guide
UG479 (v1.10) March 27, 2018
Architectural Highlights of the 7 Series FPGA DSP48E1 Slice
25-bit pre-adder with D register to enhance the capabilities of the A path
INMODE control supports balanced pipelining when dynamically switching between
multiply (A*B) and add operations (A:B)
25 x 18 multiplier
30-bit A input of which the lower 25 bits feed the A input of the multiplier, and the
entire 30-bit input forms the upper 30 bits of the 48-bit A:B concatenate internal bus.
Cascading A and B input
• Semi-independently selectable pipelining between direct and cascade paths
• Separate clock enables two-deep A and B set of input registers
Independent C input and C register with independent reset and clock enable.
CARRYCASCIN and CARRYCASCOUT internal cascade signals to support 96-bit
accumulators/adders/subtracters in two DSP48E1 slices
MULTSIGNIN and MULTSIGNOUT internal cascade signals with special OPMODE
setting to support a 96-bit MACC extension
Single Instruction Multiple Data (SIMD) Mode for three-input adder/subtracter
which precludes use of multiplier in first stage
• Dual 24-bit SIMD adder/subtracter/accumulator with two separate CARRYOUT
signals
• Quad 12-bit SIMD adder/subtracter/accumulator with four separate
CARRYOUT signals
48-bit logic unit
• Bitwise logic operations – two-input AND, OR, NOT, NAND, NOR, XOR, and
XNOR
• Logic unit mode dynamically selectable via ALUMODE
Pattern detector
• Overflow/underflow support
• Convergent rounding support
• Terminal count detection support and auto resetting
Cascading 48-bit P bus supports internal low-power adder cascade
• The 48-bit P bus allows for 12-bit/QUAD or 24-bit/DUAL SIMD adder cascade
support
Optional 17-bit right shift to enable wider multiplier implementation
Dynamic user-controlled operating modes
• 7-bit OPMODE control bus provides X, Y, and Z multiplexer select signals
Carry in for the second stage adder
• Support for rounding
• Support for wider add/subtracts
• 3-bit CARRYINSEL multiplexer
Carry out for the second stage adder
• Support for wider add/subtracts
• Available for each SIMD adder (up to four)
