Feature
Processor Cores
Intel HT Technology
®
Intel VT-x Technology
®
L1 Data Cache
L1 Code Cache
L2 Cache
L3 Cache
8.4.15

PPM Configuration Submenu

Feature
EIST
CPU C state Report
Max CPU C state
SOix
8.4.16

Thermal Configuration

Feature
DTS
Critical Trip Point
OS Hibernate Temperature
Passive Trip Point
Full Speed Fan Trip Point
Half Speed Fan Trip Point
Copyright © 2016 congatec AG
Options Description
No option Displays the number of CPU core on Socket CPU.
No option Displays the Intel
No option Displays the Intel VT-x technology support information.
No option Displays the Socket L1 data cache information.
No option Displays the Socket L1 code cache information.
No option Displays the Socket L2 cache information.
No option Displays the Socket L3 cache information.
Options Description
Disabled Enable or disable Enhanced Intel SpeedStep Technology (EIST).
Enabled
Disabled Enable or disable CPU state report to OS.
Enabled
C7 Select maximum CPU C-state supported by the CPU.
C6
C1
Disabled Enable or disable CPU SOix state support.
Enabled
Options Description
Enabled Enable or disable Digital Thermal Sensor (DTS).
Disabled
Default: 95 Set the temperature of the ACPI critical trip point at which the operating system will shut the system off.
0 - 100
Default: 85
Set the temperature that causes the operating system to trigger the system to hibernate.
0 - 110
Default: 85 Set the temperature of the ACPI passive trip point at which the operating system will begin throttling the processor.
0 - 90
Default: 80 Set the temperature at which the fan is activated at full speed.
0 - 90
Default: 60 Set the temperature at which the fan is activated at half speed.
0 - 90
HT Technology support information.
®
