Graphics Submenu - Congatec conga-IA4 User Manual

Feature
CPU Fan PWM Speed
Setting
8.4.3

Graphics Submenu

Feature
Active LFP Configuration
Always Try Auto Panel Detect No
Local Flat Panel Type
Copyright © 2016 congatec AG
Options Description
0% Select minimum/start fan speed to be set when the start temperature of the control slope is reached.
10%
20%
30%
40%
50%
60%
70%,
80%
90%
100%
Options Description
No Local Flat Panel Select the active local flat panel (LFP) configuration.
Integrated LVDS
If set to 'Yes', the BIOS will use the EDID™ data set in an external EEPROM to configure the LFP. In case it
Yes cannot be found, the data set selected under 'Local Flat Panel Type' will be used.
Auto Select a predefined LFP type or choose 'Auto' to let the BIOS automatically detect and configure the
VGA 640x480 1x18 (002h) attached LVDS panel. Auto detection is performed by reading an EDID™ data set via the video I²C bus.
VGA 640x480 1x18 (013h) The number in brackets specifies the congatec internal number of the respective panel data set.
WVGA 800x480 1x18 (01Fh) Note: Customized EDID™ utilizes an OEM defined EDID™ data set stored in the BIOS flash device.
WVGA 800x480 1x24 (01Bh)
SVGA 800x600 1x18 (01Ah)
XGA 1024x768 1x18 (006h)
XGA 1024x768 2x18 (007h)
XGA 1024x768 1x24 (008h)
XGA 1024x768 2x24 (012h)
WXGA 1280x800 1x18 (01Eh)
WXGA 1280x768 1x24 (01Ch)
SXGA 1280x1024 2x24 (00Ah)
SXGA 1280x1024 2x24 (018h)
UXGA 1600x1200 2x24 (00Ch)
HD 1920x1080 2x24 (01Dh)
WUXGA 1920x1200 2x18 (015h)
WUXGA 1920x1200 2x24 (00Dh)
Customized EDID™ 1
Customized EDID™ 2
Customized EDID™ 3
