Feature
USB Mass Storage Driver Support
Port 60/64 Emulation
USB Transfer Timeout
Device Reset Timeout
Device Power-Up Delay Selection
Device Power-Up Delay Value
SanDisk Cruzer Micro 8.01
8.4.26

Security Configuration

Feature
Relay Interface
Primary port Addr.
Lowbyte (Dec)
Primary port Addr.
Highbyte (Dec)
Relay Device Address (Dec) 0-256
BC Diagnostic Console
Interface
Copyright © 2016 congatec AG
Options Description
Disabled Enable or disable mass storage driver support.
Enabled
Disabled Enable or disable I/O port 60h/64h emulation support.
Enabled
Note: Enable this feature for the complete USB keyboard legacy support for non-USB aware operating systems.
1 sec Set the timeout value for control, bulk, and interrupt transfers.
5 sec
10 sec
20 sec
10 sec Set USB legacy mass storage device start unit command timeout.
20 sec
30 sec
40 sec
Auto Select whether the delay time for a USB device to report itself properly to the host controller should be set
Manual automatically or manually. If set to 'Auto', the delay is 100ms for a root port or the value is derived from the hub
descriptor for a hub port.
Default: 5 Set power-up delay value in seconds.
0 - 40
Auto
Select mass storage device emulation type:
Floppy 'Auto' - Enumerates devices according to their media format.
Note: Drives without media will be emulated according to the drive type.
Forced FDD
Hard Disk
CD-ROM
Options Description
Disabled
Select the relay interface to which the POST code will be redirected.
I2C
SMBus
BC Diagnostic Console
0-128 Set the Address for the primary debug port. The usual address value is 0x80. However, any multiple
of 8 is valid for a primary debug port address, i.e. the lower three bits must be zero.
0-128
Set the Address for the primary debug port. The usual address value is 0x80. However, any multiple
of 8 is valid for a primary debug port address, i.e. the lower three bits must be zero.
Specify the I2C/SMBus device Address of e.g. a 7-Segment LCD. The factory setting for the
SparkFun device is 0xE2. However, any even device address (bit 0 = 0) can be specified.
Disable Select the interface to be used for the BC Diagnostic Console output or disable the BC Diagnostic
BC AUX Port Console output.
