Table 4 Cables
Article
cab-ThinMini-ITX-SATA-Power
cab-ThinMini-ITX-UART
cab-ThinMini-ITX-USB2.0-Single
cab-ThinMini-ITX-USB2.0-Twin
cab-ThinMini-ITX-USB3.0-Twin
cab-ThinMini-ITX-LVDS-Open End
cab-ThinMini-ITX-BKLT
cab-ThinMini-ITX-LVDS
cab-DP to HDMI
cab-ThinMini-ITX-SATA-Power (50cm lenght)
cab-ThinMini-ITX-SATA-Power (30cm length)
SATA III cable (straight/straight)
SATA III cable (straight/right-angled)
Table 5 Adapters
Article
conga-Thin MITX/LVDS Adapter
conga-Thin MITX/Debug Card
Copyright © 2016 congatec AG
Part No. Description
14000120 Power cable for SATA and micro-SATA devices.
14000121 UART cable with 2x5 pin female housing and D-Sub male connector.
14000122 USB 2.0 cable with 1x5 pin female housing and USB 2.0 Type A female connector.
14000123 USB 2.0 cable with twin USB 2.0 Type A female connector and 2x5 pin housing.
14000124 USB 3.0 cable with twin USB 3.0 Type A female connector and 2x10 pin housing.
14000125 ACES 40 pin LVDS cable with open end.
14000127 CHYAO SHIUNN 8 pin backlight cable with open end.
14000129 ACES 50204-40 LVDS cable for Thin Mini-ITX.
14000128 20 pin male DP to 19 pin female HDMI
14000135 50 cm SATA power cable with 2x15 pin female connectors.
14000136 30 cm SATA power cable with 2x15 pin female connectors.
48000029 30 cm SATA III data cable with straight/straight connectors
48000030 30 cm SATA III data cable with straight/right-angled connectors
Part No. Description
052233 LVDS pin header evaluation adapter for congatec Thin Mini-ITX boards
047858 Evaluation debug card with post code display, buttons, status LED's; also for external BIOS
update and other useful IO's
