Power
Management
Other Features
Security
Note
The conga-IA4 supports only DDR3L memory modules. The memory modules in the sockets must be symmetrical - that is, same raw cards
and same memory sizes. Therefore, do not use different memory modules in the memory sockets. Doing so may cause system instability or
memory errors. Also make sure the memory modules support the data transfer rate of the particular variant.
In addition, when using one memory socket, insert the memory module only in the first memory slot on the conga-IA4 (top side). If the first
memory slot is empty, the SoC on the conga-IA4 ignores the second memory socket (bottom side). When this happens, the conga-IA4 does
not start. See the Intel's Braswell datasheet for more information.
2.2

Supported Operating Systems

The conga-IA4 supports the following operating systems.
• Microsoft Windows
®
• Microsoft Windows
®
• Microsoft
® Windows
• Microsoft Windows
®
• Linux
Note
To install Windows 7/8 and WES7/8, we recommend a minimum storage capacity of 16 GB. congatec will not offer support for systems with
less than 16 GB storage space.
2.3

Mechanical Dimensions

• 170 mm x 170 mm
• Maximum Height: 20 mm
Copyright © 2016 congatec AG
ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3)
Configurable TDP
Ultra low standby power consumption, Deep Sx
Thermal and voltage monitoring
CMOS Battery
Beeper
congatec Standard BIOS (also possible to boot from an external BIOS by triggering the BIOS_DISABLE# signal on the feature connector)
Optional discrete Trusted Platform Module "TPM 1.2/2.0", new AES Instructions for faster and better encryption
10
®
8.1
®
® 7
7/8 Embedded Standard
®
