9
Additional BIOS Features
9.1
Navigating the BIOS Setup Menu
The BIOS setup menu shows the features and options supported in the congatec BIOS. To access and navigate the BIOS setup menu, press
the <DEL> or <F2> key during POST.
The right frame displays the key legend. Above the key legend is an area reserved for text messages. These text messages explain the options
and the possible impacts when changing the selected option in the left frame.
9.2
BIOS Versions
The BIOS displays the BIOS project name and the revision code during POST, and on the main setup screen. The initial production BIOS for
conga-IA4 is identified as IA40R1xx where:
• R is the identifier for a BIOS ROM file
• 1 is the feature number
• xx is the major and minor revision number.
The IA40 BIOS binary size is 8 MB.
9.3
Updating the BIOS
OEMs often use BIOS updates to correct platform issues discovered after the board has been shipped or when new features are added to
the BIOS. The conga-IA4 uses a congatec/AMI AptioEFI firmware, which is stored in an onboard flash ROM chip and can be updated using
the congatec System Utility. The utility has five versions—UEFI shell, DOS based command line, Win32 command line, Win32 GUI, and Linux
version.
For more information about "Updating the BIOS" refer to the user's guide for the congatec System Utility "CGUTLm1x.pdf" on the congatec
website at www.congatec.com.
Copyright © 2016 congatec AG
IA40m12.indd
95/97
