Feature
►Legacy Console Redirection
Settings
Serial Port for Out-of-Band
Management / EMS
Console Redirection
►Console Redirection Settings
8.4.12.1

Console Redirection Settings Submenu

Feature
Terminal Type
Baudrate
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Resolution
Copyright © 2016 congatec AG
Options Description
Submenu Opens 'Legacy Console Redirection Settings' submenu.
Disabled Enable or disable 'Serial Port for Out-of-Band Management / Windows Emergency Management
Enabled Services'.
Submenu Opens 'Console Redirection Settings' submenu.
Options Description
VT100 Set the terminal type.
VT100+
VT-UTF8
ANSI
9600 Set baud rate.
19200
38400
57600
115200
7 Set number of data bits.
8
None Set parity.
Even
Odd
Mark
Space
1 Set number of stop bits.
2
None Set flow control.
Hardware RTS/CTS
Disabled Enable or disable the VT-UTF8 combination key support for ANSI/VT100 terminals.
Enabled
Disabled Enable this feature to only send text output over the terminal.
Enabled Note: This feature is helpful to capture and record terminal data.
Disabled Enable or disable extended terminal resolution.
Enabled
80x24 Select the number of rows and columns for the legacy operating system redirection.
80x25
