Pin Signal
27 GND
29 GND
31 -A
33 +A
35 GND
37 GND
39 +3.3V
41 +3.3V
43 Card_Type_Recognition *
45 N.C
47 N.C
49 N.C
51 N.C.
53 GND
Connector Type
X6: 0.8mm pitch, 52 pin mini PCI socket
Note
* For card presence detection, pin 21 of the mSATA card must be terminated to ground. For card type recognition, pin 43 of the mSATA card
must be unconnected.
Copyright © 2016 congatec AG
Pin Signal
28 +1.5V
30 SMB_CLK
32 SMB_DATA
34 GND
36 Reserved
38 Reserved
40 GND
42 N.C
44 N.C
46 N.C
48 +1.5V
50 GND
52 +3.3Vaux
54 GND
