Connector Description

5.1

Power Supply

You can power the conga-IA4 SBC with a 12V-24V laptop type DC power supply (on connector X43) or a 4 pin internal power supply (on
connector X44).
Additionally, the SBC offers an optional SBM
SBC with it.
Note
The supplied voltages must be within a tolerance of ± 10%
5.1.1

DC Power Jack (Rear I/O)

The conga-IA4 SBC can be powered from a laptop type external power supply connected to the DC power jack on the rear I/O. This power
input protects against polarity reversal and over/under voltage.
Table 10 Connector X43 Pinout Description
Pin Function
Inner Shell +12 - 24V
Outer Shell GND
Connector Type
X43 : DC power jack, 7.4x5.1mm diameter
Note
The conga-IA4 starts immediately power is supplied.
Caution
The absolute maximum rating of the input voltage is 36 volts. Do not exceed this rating or expose the conga-IA4 to the absolute maximum
voltage for a prolonged time. Doing so may damage the system or affect system reliability.
Copyright © 2016 congatec AG
power connector (only BOM option). When this connector (X50) is populated, you can power the
3
DC Power Jack - Connector X43
center
IA40m12.indd
DC Plug
1 = + DC (12-24V)
inner
2 = GND
+
-
12-24 V max. 120 Watt
outer
Plug: 7.4 x 5.0 mm
