Connector Description

Table 4 Primary Connector X1 Pinout (J1)
Pin Row A
A01 VCC
A02 VCC
A03 VCC
A04 VCC
A05 VCC
A06 VCC
A07 VCC
A08 VCC
A09 VCC
A10 GND
A11 BATLOW#
A12 PLTRST#
A13 GND
A14 USB7-
A15 USB7+
A16 GND
A17 USB6-
A18 USB6+
A19 GND
A20 ETH4_RX-
A21 ETH4_RX+
A22 GND
A23 ETH5_RX-
A24 ETH5_RX+
A25 GND
A26 ETH6_RX-
A27 ETH6_RX+
A28 GND
A29 ETH7_RX-
A30 ETH7_RX+
A31 GND
A32 RSVD 1
A33 RSVD 1
A34 GND
A35 ETH4_TX-
Copyright © 2022 congatec AG
Pin Row B Pin Row C
B01 VCC C01
B02 PWRBTN# C02
B03 VCC C03
B04 THERMTRIP# C04
B05 VCC C05
B06 TAMPER# C06
B07 VCC C07
B08 SUS_S3# C08
B09 VCC C09
B10 WD_STROBE# C10
B11 WD_OUT C11
B12 GND C12
B13 USB5- C13
B14 USB5+ C14
B15 GND C15
B16 USB4- C16
B17 USB4+ C17
B18 GND C18
B19 RSVD C19
1
B20 RSVD C20
1
B21 RSVD C21
1
B22 RSVD C22
1
B23 RSVD 1 C23
B24 VCC_5V_SBY C24
B25 USB67_OC# C25
B26 USB45_OC# C26
B27 USB23_OC# C27
B28 USB01_OC# C28
B29 SML1_CLK C29
B30 SML1_DAT C30
B31 PMCALERT# C31
B32 SML0_CLK C32
B33 SML0_DAT C33
B34 USB_PD_ALERT# 2 C34
B35 USB_PD_I2C_CLK C35
Pin Row D
VCC D01 VCC
RSTBTN# D02 VCC
VCC D03 VCC
CARRIER_HOT# D04 VCC
VCC D05 VCC
VIN_PWROK D06 VCC
VCC D07 VCC
SUS_S4_S5# D08 VCC
VCC D09 VCC
GND D10 WAKE0#
FAN_PWMOUT D11 WAKE1#
FAN_TACHIN D12 GND
GND D13 USB1-
USB3- D14 USB1+
USB3+ D15 GND
GND D16 USB0-
USB2- D17 USB0+
USB2+ D18 GND
GND D19 ETH0_RX-
ETH0_TX- D20 ETH0_RX+
ETH0_TX+ D21 GND
GND D22 ETH1_RX-
ETH1_TX- D23 ETH1_RX+
ETH1_TX+ D24 GND
GND D25 ETH2_RX-
ETH2_TX- D26 ETH2_RX+
ETH2_TX+ D27 GND
GND D28 ETH3_RX-
ETH3_TX- D29 ETH3_RX+
ETH3_TX+ D30 GND
GND D31 USB3_SSTX-
USB3_SSRX- D32 USB3_SSTX+
USB3_SSRX+ D33 GND
GND D34 USB2_SSTX-
USB2_SSRX- D35 USB2_SSTX+
HEVAm100 15/54
