Connector Description

5.1

You can power the conga-IA5 SBC with:

• a 12V-24V laptop type DC power supply on connector X43 (default for commercial variants / assembly option for industrial variants)

• a 4-pin power supply on connector X44/X48 (X44 default for all variants / X48 assembly option)

• an optional SBM

Note

The supplied voltages must be within a tolerance of ± 10%. The conga-IA5 may not function if you exceed this tolerance limit.

5.1.1

The conga-IA5 SBC can be powered from a laptop type external power supply connected to the DC power jack on the rear I/O. The power

input is protected to a short transient over-voltage and ESD.

Table 11

DC Power Jack (X43 Connector) Pinout Description

Function

Inner Shell

+12 - 24V

Outer Shell

GND

Connector Type

X43: DC power jack, 7.4x5.1mm diameter

Note

The conga-IA5 industrial variants do not have DC power jack (connector X43). They are equipped with internal power connector (X44) only.

Caution

The absolute maximum rating of the input voltage is 36 volts. Do not exceed this rating or expose the conga-IA5 to the absolute maximum

voltage for a prolonged time. Doing so may damage the system or affect system reliability.

power supply on connector X46 (assembly option)

IA50m01

23/59
