4

Connector Description

Table 5
SMARC Edge Finger Connector Pinout
P-PIN Primary (Top) Side
P1
SMB_ALERT#
P2
GND
P3
CSI1_CK+
P4
CSI1_CK-
P5
GBE1_SDP
P6
GBE0_SDP
P7
CSI1_RX0+
P8
CSI1_RX0-
P9
GND
P10
CSI1_RX1+
P11
CSI1_RX1-
P12
GND
P13
CSI1_RX2+
P14
CSI1_RX2-
P15
GND
P16
CSI1_RX3+
P17
CSI1_RX3-
P18
GND
P19
GBE0_MDI3-
P20
GBE0_MDI3+
P21
GBE0_LINK100#
P22
GBE0_LINK1000#
P23
GBE0_MDI2-
P24
GBE0_MDI2+
P25
GBE0_LINK_ACT#
P26
GBE0_MDI1-
P27
GBE0_MDI1+
Copyright © 2020 congatec AG
S-Pin
Secondary (Bottom) Side
S1
CSI1_TX+ / I2C_CAM1_CK
S2
CSI1_TX- / I2C_CAM1_DAT
S3
GND
S4
RSVD
2
S5
CSI0_TX- / I2C_CAM0_CK
S6
CAM_MCK
S7
CSI0_TX+ / I2C_CAM0_DAT
S8
CSI0_CK+
S9
CSI0_CK-
S10
GND
S11
CSI0_RX0+
S12
CSI0_RX0-
S13
GND
S14
CSI0_RX1+
S15
CSI0_RX1-
S16
GND
S17
GBE1_MDI0+
S18
GBE1_MDI0-
S19
GBE1_LINK100#
S20
GBE1_MDI1+
S21
GBE1_MDI1-
S22
GBE1_LINK1000#
S23
GBE1_MDI2+
S24
GBE1_MDI2-
S25
GND
S26
GBE1_MDI3+
S27
GBE1_MDI3-
S28
GBE1_CTREF
SMC1m10
