3. Mounting
3.1 AGC 200 mounting and dimensions
3.1.1 Mounting of the unit
The unit is designed for mounting in the panel front.
3.1.2 Unit dimensions
Dimensions are given in mm (inches).
DEIF A/S
312 (12.28)
297 (11.69)
Mounting
87 (3.43)
8 (0.31)
Page 17 of 67
