AGC 200 installation instructions
4189340610 UK
Plug #10, mains AC voltage inputs
Term. Function
68 L 1
69
70 L 2
71
72 L 3
73
74 N
75
76
All AC voltage inputs are galvanically separated from the rest of the unit. Voltages are indica-
ted in phase-phase values.
Plug #11, digital inputs and breaker positions
Term. Function Technical data Description
77 Di 77 Optocoupler
78 Di 78 Optocoupler
79 Di 79 Optocoupler
80 Di 80 Optocoupler
81 Di 81 Optocoupler
82 Di 82 Optocoupler
83 Di 83 Optocoupler
84 Di 84 Optocoupler
85 Di 85 Optocoupler
86 Di 86 Optocoupler
87 Di 87 Optocoupler
88 Di 88 Optocoupler
89 Di GB ON Optocoupler
90 Di GB OFF Optocoupler
91 Com Common
92 Not used
93 Di D+
The digital inputs 77 to 90 are bi-directional, meaning that common can be - or +, whichever is
preferred.
Terminals 77 to 81 are not available in AGC 21x and 22x.
DEIF A/S
Technical data
100 to 690 V AC
Not used
100 to 690 V AC
Not used
100 to 690 V AC
Not used
Not used
Not used
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
MB ON/configurable
MB OFF/configurable
Gen. breaker ON feedback
Gen. breaker OFF feedback
Common for inputs 77 to 90
Charger generator D+ running feedback and digital running feed-
back
Hardware
Description
Mains line 1
Mains line 2
Mains line 3
Mains neutral
