AGC 200 installation instructions
4189340610 UK
Plug #8, AC current inputs
CT on terminals 59-60: Not available for AGC 21x/22x.
Term. Function Technical data Description
53 L1 s1 1 or 5 A AC
54 L1 s2
55 L2 s1 1 or 5 A AC
56 L2 s2
57 L3 s1 1 or 5 A AC
58 L3 s2
59 L4 s1 1 or 5 A AC
60 L4 s2
Plug #9, generator AC voltage inputs
Term. Function
61 L 1
62
63 L 2
64
65 L 3
66
67 N
All AC voltage inputs are galvanically separated from the rest of the unit. Voltages are indica-
ted in phase-phase values.
DEIF A/S
Current phase L1
Current phase L2
Current phase L3
Configurable: Differential current, neutral current, ground current or
mains current
Technical data
100 to 690 V AC
Not used
100 to 690 V AC
Not used
100 to 690 V AC
Not used
Description
Generator line 1
Generator line 2
Generator line 3
Generator neutral
Page 25 of 67
Hardware
