Deif AGC 200 Installation Instructions Manual page 61

AGC 200 installation instructions
4189340610 UK
2 1
OFF
CAN 1
ON
6 5 4 3 2 1
End resisto r
120
Gnd CAN H
If option H8 is used together with AOP-2, the total end resistance of the AOP-2 and the external
I/O controller must be 120 Ω.
A DC/DC converter for the DC supply voltage and 2 × 1 m cable with an RJ12 plug in one end
and stripped wires in the other end are included in the AOP-2 delivery.
DEIF A/S
CAN 2
6 5 4 3 2 1
Comm. to
other units
Status relay
5V DC
+ -
Output
Input
CAN L
+ -
24V DC
Power
supply
Wirings
Page 61 of 67
