AGC 200 installation instructions
Mounting
4189340610 UK
3.1.3 Panel cutout
204 (8.03)
Dimensions are given in mm (inches).
3.1.4 Mounting instructions
Fasten the unit with the screw clamps supplied with the unit. These are to be tightened 0.15-0.20 Nm - see
diagram in the chapter Unit dimensions.
3.1.5 Mounting of gasket (option L1)
It is important that the gasket is mounted correctly; otherwise the IP65 tightness will not be obtained.
DEIF A/S
Page 18 of 67
