AGC 200 installation instructions
4189340610 UK
Plug #8, AC current inputs
Term. Function
53 L1 s1
54 L1 s2
55 L2 s1
56 L2 s2
57 L3 s1
58 L3 s2
59
60
Plug #9, mains/busbar A AC voltage inputs
Term. Function
61 L 1
62
63 L 2
64
65 L 3
66
67 N
All AC voltage inputs are galvanically separated from the rest of the unit. Voltages are indica-
ted in phase-phase values.
Plug #10, busbar/busbar B AC voltage inputs
Term. Function
68 L 1
69
70 L 2
71
72 L 3
73
74 N
75
76
All AC voltage inputs are galvanically separated from the rest of the unit. Voltages are indica-
ted in phase-phase values.
DEIF A/S
Technical data
1 or 5 A AC
1 or 5 A AC
1 or 5 A AC
Not used
Technical data
100 to 690 V AC
Not used
100 to 690 V AC
Not used
100 to 690 V AC
Not used
Technical data
100 to 690 V AC
Not used
100 to 690 V AC
Not used
100 to 690 V AC
Not used
Not used
Not used
Description
Current phase L1
Current phase L2
Current phase L3
Description
Mains line 1 (AGC 244: BB A)
Mains line 2 (AGC 244: BB A)
Mains line 3 (AGC 244: BB A)
Neutral
Description
Busbar line 1 (AGC 244: BB A)
Busbar line 2 (AGC 244: BB A)
Busbar line 3 (AGC 244: BB A)
Neutral
Hardware
