AGC 200 installation instructions
4189340610 UK
Response times Busbar:
(Delay set to
Over-/under-voltage: < 50 ms
minimum)
Over-/under-frequency: < 50 ms
Generator:
Reverse power: <200 ms
Over-current: <200 ms
Short circuit: < 40 ms
Directional over-current: <100 ms
Over-/under-voltage: <200 ms
Over-/under-frequency: <300 ms
Overload: <200 ms
Current unbalance: <200 ms
Voltage unbalance: <200 ms
React. power import: <200 ms
React. power export: <200 ms
Negative sequence I: <400 ms
Negative sequence U: <400 ms
Zero sequence I: <400 ms
Zero sequence U: <400 ms
Overspeed: <400 ms
Digital inputs: <250 ms
Analogue input: <250 ms
Emergency stop: <200 ms
Earth current: <100 ms
Mains:
df/dt (ROCOF): <130 ms
(4 periods)
Vector jump: < 40 ms
DEIF A/S
Technical information
Page 66 of 67
