AGC 200 installation instructions
4189340610 UK

5.2.13 Stop coil

+12/24V DC
20
21
0V DC
Remember to mount the freewheeling diode.
The wire break detection is only active when the output is OFF.
DEIF A/S
Relay Wire break
detection
Wirings
Page 56 of 67
