AGC 200 installation instructions
4189340610 UK
Plug #2, communication
Term. Function
4 Data+ (A)
5
6 Data+ (B)
7 CAN A H
8
9 CAN A L
10 CAN B H
11
12 CAN B L
13 CAN C H
14
15 CAN C L
Plug #3, relay group 1
Term. Function
16 Relay 16
17
18 Relay 18
19
20 Relay 20
21
22 Not used
23 Relay 23
24
Plug #4, E-stop and start
Term. Function
25 +12/24 V DC Digital in
26 Relay 26
27 Relay 27
DEIF A/S
Technical data Description
RS-485 Modbus RTU, max. 115 kBps
CAN port A Power management, AOP-2 and external I/O modules
CAN port B Power management, AOP-2 and external I/O modules
CAN port C Not used
Technical data
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
8 A, 36 V DC
Description
Status OK/configurable
Horn/configurable
Configurable
Not used
Configurable
With wire break monitoring
Technical data
Optocoupler
16 A, 36 V DC
16 A, 36 V DC
Hardware
Description
Emergency stop
Not used
Not used
Page 30 of 67
