Plug #5, relay group 2
Not available for AGC 21x/22x.
Term. Function
28 Relay 28
29
30 Relay 30
31
32 Relay 32
33
34 Relay 34
35
Plug #6, GB and MB relays
Term. Function
36 NC Relay
Com 36
37
NO
38
39 Relay 39
40
41 Relay 41
42
43 NC Relay
Com 43
44
NO
45
Plug #7, multi-inputs and RPM pickup
Term. Function
46 Multi-in 1
47 Multi-in 2
48 Multi-in 3
49 Common
50 MPU
51 Com
52 W
DEIF A/S
Technical data
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
Technical data
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
8 A, 30 V DC/250 V AC
Technical data
Input
Input
Input
Input
RPM input
Common
RPM input
Description
Mains breaker ON/configurable
Mains breaker OFF/configurable
Generator breaker ON
Generator breaker OFF
Description
RMI/4 to 20 mA/Pt100/binary
RMI/4 to 20 mA/Pt100/binary
RMI/4 to 20 mA/Pt100/binary
Com. for inputs 46, 47 and 48
Magnetic pickup/tacho generator
Com. for inputs 50 and 52
Charge gen. W NPN/PNP pickup
Hardware
Description
Configurable
Configurable
Configurable
Configurable
