AGC 200 installation instructions
4189340610 UK
Terminal 93 (D+) has two purposes. See chapter 6 for details.
The placement of terminals (top, bottom, left, right) is seen from the rear side of the unit.
Terminals 77 to 81 are not available in AGC 21x and 22x.
Input/output lists
In the I/O lists below, the following terms will be used in connection with the relay outputs:
NO means Normally Open
NC means Normally Closed
Com. means common terminal
Plug #1, power supply
Term. Function
1 +12/24 V DC
2 0 V DC
3
DEIF A/S
Technical data
12/24 V DC +/-30 %
Not used
Hardware
Description
Power supply
