5. Wirings

5.1 AC connections

5.1.1 AC connections
The AGC 200 can be wired up in three-phase, single phase or split phase configuration.
Contact the switchboard manufacturer for accurate information about required wiring for the
specific application.

5.1.2 Neutral line (N)

When three-phase distribution systems are used, the neutral line (N) is only necessary if it is a three-phase +
neutral system. If the distribution system is a three-phase system without neutral, then leave the terminals 67
and 74 empty.

5.1.3 Current transformer ground

The current transformer ground connection can be made on s1 or s2 connection, whichever is preferred.

5.1.4 Voltage measurement fuses

If the wires/cables are protected with fuses, use 2 A slow blow or higher, dependent on the wires/cables being
protected.

5.1.5 Breaker wiring

The breaker wiring is an example only.
