AGC 200 installation instructions
4189340610 UK
1-phase and 2-phase systems are also supported.
The application shown is for pulse breakers.
Be aware that the inputs for feedbacks shown above also need a common wire on terminal 91.
(Terminal 91 is common for 77 to 90).
DEIF A/S
Wirings
Page 46 of 67
