AGC 200 installation instructions
4189340610 UK
Relay outputs, Relays 16 to 20 and 28 to 43: 250 V AC/30 V DC 8 A
electrical rating UL/cUL Listed: 250 V AC/30 V DC 6 A General use B300 Pilot duty
Relay 23: 36 V DC 8 A
UL/cUL Listed: 24 V DC 8 A General use
Relay 26 and 27: 36 V DC 16 A
UL/cUL Listed: 24 V DC 16 A General use
Galvanic sepa- Between AC voltage and other I/Os: 3250 V AC, 50 Hz, 1 minute
ration Between AC current and other I/Os: 2200 V AC, 50 Hz, 1 minute
AGC 222, 232 Between relay outputs and other I/Os: 2200 V AC, 50 Hz, 1 minute
AGC 242, 243 Between aux. supply and other I/Os: 550 V AC, 50 Hz, 1 minute.
AGC 244 Between binary input groups and other I/Os: 550 V AC, 50 Hz, 1 minute
AGC 245, 246 Between analogue input groups and other I/Os: 550 V AC, 50 Hz, 1 minute
AGC 212, 213 The same as above, but with no galvanic separation on analogue input groups
Mounting Panel-mounted
Front size 312 × 219 mm (122.8 × 86.2 in)
Panel cutout 297 × 204 mm (11.69 × 8.03 in)
Tolerance: +0.4/-0 mm
Display 240 × 128 pixel backlight STN
Safety To EN 61010-1, installation category (over-voltage category) III, 600 V, pollution degree
2
To UL508 and CSA22.2 No. 14-05 Installation category (over-voltage category) III, 600
V, pollution degree 2
Protection Front: IP52/NEMA type 1 (IP66/NEMA type 1 with gasket, option L1)
Terminals: IP20/NEMA type 1 To IEC/EN 60529
EMC/CE To EN 61000-6-1/2/3/4
IEC 60255-26
IEC 60533 power distr. zone
IACS UR E10 power distr. zone
Vibration 3 to 13.2 Hz: 2 mm
10 to 60 Hz: 0.15mm
10 to 150 Hz: 2 g. To IEC 60255-21-1 Endurance (class 2)
Shock 10 g, 11 ms, half sine. To IEC 60255-21-2 Response (class 2)
30 g, 11 ms, half sine. To IEC 60255-21-2 Endurance (class 2)
50 g, 11 ms, half sine. To IEC 60068-2-27
Bump 20 g, 16 ms, half sine. To IEC 60255-21-2 (class 2)
Material All plastic materials are self-extinguishing according to UL94 (V1)
DEIF A/S
. 13.2 to 100 Hz: 0.7 g. To IEC 60068-2-6 and IACS UR E10
pp
. 60 to 150 Hz: 1 g. To IEC 60255-21-1 Response (class 2)
pp
Technical information
Page 64 of 67
