Figure 3 Connection Module — Expanded View
1
2
Item
Description
1
Locking screw
2
RS-232 serial port, Molex three-pin connector
3
General purpose status light
4
Activity/status light for disk 0
5
Activity/status light for disk 1
6
Power status light
7
USB connector (type A)
8
Locking screw
3
5
4
6
Gateway Installation
7
8
349
