3Com 3102
Business Telephone
During the downloading process, several progress messages appear in
the telephone display panel. After the software has been downloaded to
the telephone, the message "Local Phone Number:" appears.
To log in on the telephone, a user enters:
An extension number, followed by #
■
A numeric password, followed by #
■
To assign a telephone extension to a user, you must configure the
telephone extension number and user ID using the VCX Administrator
User Interface. For information about how to perform these tasks, see the
VCX Administration Guide.
The easiest way to install any 3Com telephone assumes that the
telephone obtains an IP address from a DHCP server. If your network does
not provide IP addresses through a DHCP server, you must manually
configure the IP address of the telephone.
Configuring the 3102 Telephone with a DHCP Server
To configure the 3Com 3102 Business Telephone:
1 Plug one end of a Category 5 Ethernet cable into the connector on the
3102 Business Telephone.
2 Plug the other end of the Ethernet cable into the appropriate data jack on
your network.
3 Plug the power cord into an AC power receptacle.
4 Plug the other end of the power cord into the power connector on the
telephone.
5 Press the Program button, located at the top of the row of buttons on
the right side of the telephone.
6 Press 5 (Set NCP IP).
7 Enter the IP address of the Primary VCX Call Processing Server.
VCX systems typically have two Call Processing servers. One is the primary
server and the other is the alternate server, which is available for fail-over
purposes.
8 Press # to save the new setting.
9 Press the Program button.
10 Press 6 (VCX Cnfig Menu).
Telephone Installation 331
