348
C
9: I
HAPTER
NSTALLING
D
EVICES
Figure 2 CPU Module — Expanded View
1
2
Item
Description
1
Locking screw
2
Dry contact ports (2)
3
Audio In/Out
4
10/100 Ethernet port (has activity and link status lights)
5
10/100 Ethernet port (has activity and link status lights)
6
RS-232 port
7
Locking screw
8
Reset button access (button is located behind the front panel)
3
4
8
6
5
7
