Parameters
4.4 Outputs
Scope and application
Outputs are used, e.g. for controlling motor contactors, displaying states or signaling via the
communication bus. The system provides different types of output depending on the device
series and the expansion modules in use:
Table 4- 50 Outputs
Outputs
Basic unit outputs (BU Outputs)
Operator panel LEDs (OP LED)
Digital module 1 outputs (DM1
Outputs)
Digital module 2 outputs (DM2
Outputs)
Analog module output (AM1
output/AM2 output)
Acyclic send data (Acyclic send)
OPC-UA send
Cyclic send data (Cyclic send)
1) for the SIMOCODE pro S basic unit, the DM1 outputs are on the multifunction module.
2) only AM1 output available
