Filters; Print Channel Groups; Cue List Display / Editor; Cue Lists - Strand Lighting NEO User Manual

The column used to sort the channel groups will be indicated by a small triangle to the right of the column name.

Filters

Use the "Show All Groups" button to select the filter mode you want. To make it easier to manage a large number of
channel groups you can turn off different groups by what shortcuts and submasters are assigned. The current filter
being applied will be shown in the button title.

Print Channel Groups

Click on the "Print" button to print out the channel groups in this show.
A drop down menu can be accessed by clicking on the right of this button. The resulting menu will provide access to
a preview window and the printer setting control.
The drop down menu also provides the ability to import and export the channel group list to a standard comma
separated (CSV) file format.

13. Cue List Display / Editor

To access the cue list editor click on the "Cue List Editor" button on the Command Line interface window or press F4
on your keyboard.
Shows consist traditionally of a list of cues each of which contains a defined lighting state and/or effect sequence. A
cue can be considered any point in a live show when a signal is given for a lighting change to take place. When a cue
is triggered, the lighting state becomes active and channels attached to the cue will be set to their preset levels.

14. Cue Lists

NEO provides the ability to create multiple cue lists to help manage and run complex shows. A "cue list" is a way to
collect a number of cues and assign a name or short description.
Examples of how cue lists can be used include;
• Separate different "Acts" within a show.
• Manage a number of shows all running in a single venue.
• Create separate shows for a number of songs likely to play in a concert or venue.
NEO Lighting Control Console
Cue List Display / Editor
87
