Manually Changing a Palette in a Cue

The channel detail window can also be used to manually change palette references. If in the example above we
wanted to remove the palette references for "P/T Speed" and change channel 3 and 4 to blue rather than magenta.
Do this by clicking on the "Palettes" tab of the channel detail window to view only palette information for this cue.
To remove a palette click on the cell and press the backspace key to clear out the entry. Once cleared press the enter
key and the cell will change to "Not set" indicating that no palette is referenced for this attribute any more.
To change a palette reference select the desired palette from the left hand panel (Blue in the example) and drag and
drop it onto the cell you want to replace.
Alternatively you can click in the field you want to change and simply type the name of the palette you want to
reference. As you type a list will appear below the cell of all the palettes that match what you have typed so far. Use
the up and down arrow to select from the list and press enter to apply the selected palette. You can also select a palette
from the list using the mouse.
You can also edit multi palettes at the same time by highlighting multiple cells and typing the name of the palette to
apply. As soon as the palette is selected it will be saved to all of the selected cells.
You will notice that when editing palettes in this window both palettes and channel groups are displayed as a merged
list. Any attribute in a cue can reference a channel group or a palette and so the two types are merged to make
selection easier.
