Timing

To set an individual fade time for any attribute use the timing tab to enter a time value in seconds. If the value shows
"Not set" then no independent fade time exists. Any fade time set here will override the channel fade time and the
group fade time when the group value is set or the group applied.

Delay

To set an individual delay time for any attribute use the delay tab to enter a time value in seconds. If the value shows
"Not set" then no independent delay exists. Any delay set here will override the channel delay when the group value
is set or the group applied.

Channel Grid

The channel grid view displays the channels in the grid as they would appear in the channel display window. You can
switch between the various view modes used in the main channel display by clicking on the "View" menu - this
includes expanded, compact and Classic views. In the same view menu you can choose to display only the channels
currently in the group or all channels in the system. If all channels are shown then the ones not currently included in
the group will be display with a light grayed text.
In this view selected channels can be removed by clicking on the "Remove Selected" button and if all system
channels are shown you can add selected channels using the "Add Selected" button.

Matrix

Use the matrix view to work with the channels in the group as they are laid out in the pre-defined matrix. For more
information about using this view see the section "Matrix View" in the Cue list details section.

Add/Delete

The final tab provides convenient options for adding and removing channels from the group.
