changes. The dimmer patching window is the only place in NEO where you specifically need to save your work. In
all other windows the changes are automatically saved with every change.
Dimmer Patch Window
NEO NOTES & TIPS: You will notice that dimmer 6 is now "unpatched". This is because channel 6 that use to be
patched to dimmer 6 is now holding the Mac 250 we have just patched. Also channels 26 thought to 43 are now blank
and do not contain any patch information. This is because the dimmers that where patched to these channels are now
in use by the Mac 250 that we just patched. NEO will allow you to overlap patch information but by default it will
assume this undesirable and automatically unpatch the channels for you.
We are now ready to use this fixture in the channel window as desk channel 6. To patch other moving lights, simply
repeat the procedure above patching each light into the desired channel.
NEO NOTES & TIPS: You can patch multiple fixtures of the same type all at once by changing the quantity (Qty)
number in the available fixtures section of the window.

Controlling a Moving Light

STEP 1
Open the channel window again (if not already open) and click on the "Clear Selection" button along the top of the
window.
You will now have only the channels that are active highlighted.
STEP 2
Have a close look at channel six and notice that the content of the cell has changed. It is now labeled "Fixture: 6" and
below the label is the name of the fixture followed by its attributes.
STEP 3
Click and select channel 6 and as well as highlighting the cell. The fixture control window will appear and attach
itself to the right-hand side of the channel window.
Channel Display Window Showing Fixture Control
