NEO Lighting Control Console
Right Click Menu
Right clicking anywhere in the channel grid will bring up the context menu for this window. This is the same menu as
the dropdown off the "Remove Channels" button.
Copy selected channels to another step - Use the sub menu to select a chase step to copy the current selection to.
The state of the channels will also be copied.
Turn off attributes - To remove an attribute type from the step select the channels and then select from this menu
what you want to remove. In the case of color mixing you can use the submenu to select individual colors or remove
all colors.
Random - Use the submenu to set an attribute type to random values for the selected fixtures.
Turn off in all steps - To turn off attributes in all fixtures and all steps use the sub menu to select the type.
Matrix View
An alternative way to view a chase step is the matrix view. You can switch between the matrix view and channel view
by using the buttons in the top right of the window.
In the matrix view the step is shown as it looks from the point of view of a defined matrix.
Chase editor, Matrix View
Use the drop down combo to select the matrix you want to view as the chase step. You can work with as many
matrices as you want and each will work independently of each other. Because the matrix view is just another way to
edit the underlying channels you can switch matrix at any time and no information will be lost.
This view works like a painting canvas with each grid cell being a position in the matrix that we can set to a color.
Use the "Pen" option to select a color and then click anywhere in the matrix grid to paint the color. As soon as a color
is painted the channel will automatically be added to the chase step. If the channel already exists then it will be
updated to reflect the pained color.
