User's Manual
Pause
Pausing an effect will stop its execution immediately but keep the position pointer at the current location. If you start
the effect again (press "play" button), the effect will continue from this location.
Rewind
Pressing the rewind button will stop the effect and resets its position back to the start. If the effect is restarted, it will
start from the beginning. This will also release the channels used in the effect.
Selecting a Different Effect
To change the current effect being edited click on the desired effect name in the list on the left of the window. The
name of the currently selected effect will appear at the top of the effects grid to show which effect you are working
on.
Deleting an Effect
To remove an effect form the system select it form the list and click on the "Delete" button at the bottom of the
window. A confirmation dialog will ask if you are sure you want to remove the effect.
Right click Options
Right click on any of the effects for options to rename the effect, make a copy of the effect, create an effect playback
or add the effect to the library (profile effects only).
These options can also be accessed from the "Options" button at the bottom of the window.
Note: This list may vary depending on the effect type you select.
Rename This Effect
This assigns a different name to the selected effect.
Make a Copy of This Effect
This copies the selected effect when it's easier to start from an existing effect.
1 1 6
Software Configuration
