Edit Image - The edit image option will open a paint window that will allow you to modify or paint any image you
want.
Edit Shortcut - Select this option to open the editor window associated with this shortcut.
Move Shortcut - Upon selecting the move shortcut option your mouse pointer will change to a small hand. Click on
any unassigned shortcut to move the original to this cell.
Lock/unlock shortcut - A locked shortcut will remain on screen regardless of the page change. This is useful for
keeping some operations on screen all of the time.
Add Quick Command (macro) - If you right click on a shortcut that is not assigned you will get a single menu item
"Add Quick Command". This is a special function that will allow you to assign a single command function to the
shortcut key. You can think of this as a one line macro that is assigned directly to the shortcut key.
After selecting this option a dialog will appear asking you to enter the command you want to assign. The command
can be any valid command line text (You may want to test your command in the command line window before
entering it here). Once entered click on the "OK" button to assign the new command. The command entered will
become the description for the shortcut.
NEO NOTES & TIPS: Clicking on the shortcut will cause the command to be immediately executed in the
command line window.
The full screen button to the right of the text size edit box allows you to toggle the window into a borderless full
screen mode. This can be useful when using the shortcuts page with a touch screen monitor. The window can be
returned to its original size by clicking on the same button.
4. Submasters and Submaster Pages

Submaster Options

Submasters can be assigned to perform a number of functions. Traditionally a submaster is a physical slide control
that allows the user to input a value between 0 and 255.
The following functions can be assigned to NEO submasters:
• Channel groups (Scenes & Submasters)
• Cue "go" execution
• Cue intensity override
• Effect Playbacks intensity override
• Chase step rate control
• Chase fade time control
NEO provides up to 100,000 submasters that are accessed through pages. The "System Properties" will allow you to
specify how many pages the system creates and how many submasters (up to 100) per page.
Obviously, computers do not typically come with a number of physical faders so NEO provides access to submasters
through either an on-screen interface or through add-on hardware.
Open Submaster Page
Submaster Page Control
