User's Manual
The "IF" command will reference the position, purpose and color description fields. It will also reference palettes and
groups that are used by fixtures. If for example I apply a channel group as a position preset called "Position DSL" the
"IF" statement can find it by simply typing "IF Position DSL" (not case sensitive).
NEO NOTES & TIPS: IF @40 | >70 - Select all fixtures at 40% or greater than 70%.
NEO NOTES & TIPS: IF @40 &! L015 - Select all fixtures at 40% that are not using L015 as their filter (L015
could be a color description or palette)
NEO NOTES & TIPS: IF position DSL & Red &! wide zoom - Select fixtures in position DSL that are red but not
in a wide zoom. In the above example "Red' can mean a color description and a palette reference.
VIEW
The "View" command is used to filter the channel display so that you can focus on a specific list of channels that you
want to control. This command can filter the channel display by a group name, group number or an "if" statement.
To clear a view from and return to displaying all channels use the "Clear" command as you would to clear channel
selection.
NEO NOTES & TIPS: view if @35 - Select all fixtures at 35% and turn this into a view.
NEO NOTES & TIPS: view 12 - Display only the channels in group ID 12
NEO NOTES & TIPS: view SC Vocal - Display only the channels in the group labeled "SC Vocal"
CUE
The "cue" command can be used to execute cues in the system or record new cues.
CUE PLAYBACK {Playback number} {cue number, GO, STOP, BACK, RESET}
The above command will execute a cue on a specific cue playback. You can either enter a specific cue number or use
the keywords GO, STOP, BACK, and RESET to control the playback.
NEO NOTES & TIPS: cue playback 2 go - This will execute the next cue on playback 2.
CUE {Cue List} {Cue Number, GO, STOP, BACK, RESET}
The above command will execute a cue on the master playback in the "Cue List Editor" window. You can optionally
enter a different cue list, cue number or use the keywords GO, STOP, BACK, and RESET to control the playback.
NEO NOTES & TIPS: cue "Act 1" go - This will execute the next cue on the cue list "Act 1" if this cue list is not the
active cue list then it will become the active cue list and the first cue will be executed.
NEO NOTES & TIPS: cue "Act 1" 3.4 - This will execute cue 3.4 on the cue list "Act 1".
