Submaster Wheel

On the right hand side of this window is a large wheel that can be used to move all of the submasters on this page at
once. Click on the wheel and while holding the mouse button down move the mouse up or down to raise or lower the
levels. You will see all of the submasters on that page raise and lower with your mouse movements.
You can select what submasters the wheel will operate on by clicking to the left of the slider for each of the
submasters. The master wheel will operate on all submasters that have the small green tick in the bottom left corner.

Grid Mode

Setting submasters in the grid mode is similar to setting channels in the channel display. Each submaster is
represented by a cell in a two dimensional grid.
Figure 11: Submaster Window - Grid Mode
Submasters can be selected by simply clicking on the desired grid cell. By holding the left mouse button down you
can drag an area of the grid to select multiple submasters. Once selected use the mouse wheel or the spin wheel on the
right to change the value.
Right click on any of the cells in the grid for additional options.
Clear selection - Select this option to unselect all submasters.
Select active submasters (all pages) - All of the submasters currently above zero will be selected.
Clear selection when changing pages - Check this menu item so that all of the submasters are automatically
unselected when the page is changed.
Inclusive selection mode - This is toggle option that will have a small check mark next to it when turned on. If the
"inclusive selection" option is active then each selection made will be added to the previous selection. All submasters
currently selected will remain selected unless they are in the new selection area. Any selection will toggle the
selection state of a channel.
On the right hand side of the submaster page are the split playback faders for the primary cue list. This includes a
Stop/Back and GO buttons.
